Gree GW09-6DCR Primo 1.0 HP Wall Mounted Split Type Full DC Inverter Aircon

0 out of 5
(No Customer Review)
This product is available

Original price was: ₱41,999.00.Current price is: ₱31,500.00.

or pay as low as 3,500.00/mo for 12 months using BDO credit cards
Installment Options
12 Months₱ 3,500.00
9 Months₱ 4,666.66
6 Months₱ 7,000.00
3 Months₱ 14,000.00
SKU: GW09-6DCR Category: Tag:

Description

TECHNICAL SPECIFICATIONS:



WHOLE PART SECTION

Rated horse power HP: 1.0

W 2900

Cooling capacity <min/max> <300~3650>

kJ/h 10439.23

<min/max> <1080.32~13138.97>

CSPF :7.01

EER: (kJ/h)/W 15.2

Power supply    Volts    220 <198/242>

<min/max>

Frequency Hz 60

Phases – 1

Cooling Power input  Volts    688 <130~1100>

<min/max>

Cooling Current A 3.7

Rated input W 1100

Rated current A 5.6

Airflow volume (SS/H/MH/M/ML/L/SL) m3/h 700/630/560/490/420/390/360

Dehumidifying volume L/h 0.80

Application area m2 12-18



FAN SECTION

Fan Diameter Length(D×L mm φ98×630

Cooling speed r/min 1350/1200/1000/650

Fan Motor Power Output W 15

Fan Motor RLA A 0.22

Fan Motor Capacitor  μF



EVAPORATOR SECTION

Evaporator Pipe Diameter mm φ5

Evaporator Row-fin Gap mm 2-14

Coil Length (L×D×W) mm 634×22.8×304.8



PARAMETER INFORMATION

Swing Motor Power Output W 1.5/1.5/1.5

Fuse Current A 3.15

Set Temperature Range  C 16～30



INTERIOR SIDE SECTION

Sound pressure level (SS/H/MH/M/ML/L/SL) dB(A) 42/38/36/33/28/24/20

Actual dimension (WxHxD) mm 825×293×196

Package dimension (LxWxH mm 875×365×268

Stacked Layers – 8

Net weight kg 9.5

Gross weight kg 11.5

TECHNICAL SPECIFICATIONS:



WHOLE PART SECTION

Rated horse power HP: 1.0

W 2900

Cooling capacity <min/max> <300~3650>

kJ/h 10439.23

<min/max> <1080.32~13138.97>

CSPF :7.01

EER: (kJ/h)/W 15.2

Power supply    Volts    220 <198/242>

<min/max>

Frequency Hz 60

Phases – 1

Cooling Power input  Volts    688 <130~1100>

<min/max>

Cooling Current A 3.7

Rated input W 1100

Rated current A 5.6

Airflow volume (SS/H/MH/M/ML/L/SL) m3/h 700/630/560/490/420/390/360

Dehumidifying volume L/h 0.80

Application area m2 12-18



FAN SECTION

Fan Diameter Length(D×L mm φ98×630

Cooling speed r/min 1350/1200/1000/650

Fan Motor Power Output W 15

Fan Motor RLA A 0.22

Fan Motor Capacitor  μF



EVAPORATOR SECTION

Evaporator Pipe Diameter mm φ5

Evaporator Row-fin Gap mm 2-14

Coil Length (L×D×W) mm 634×22.8×304.8



PARAMETER INFORMATION

Swing Motor Power Output W 1.5/1.5/1.5

Fuse Current A 3.15

Set Temperature Range  C 16～30



INTERIOR SIDE SECTION

Sound pressure level (SS/H/MH/M/ML/L/SL) dB(A) 42/38/36/33/28/24/20

Actual dimension (WxHxD) mm 825×293×196

Package dimension (LxWxH mm 875×365×268

Stacked Layers – 8

Net weight kg 9.5

Gross weight kg 11.5

Reviews

There are no reviews yet.

Be the first to review “Gree GW09-6DCR Primo 1.0 HP Wall Mounted Split Type Full DC Inverter Aircon”

Your email address will not be published. Required fields are marked *

FAQ’s
Q: Installation cost included and other accessories included Gree GW09-6DCR Primo 1.0 HP Wall Mounted Split Type Full DC Inverter Aircon?
A: Installation cost is not included.

Q: What is the warranty Gree GW09-6DCR Primo 1.0 HP Wall Mounted Split Type Full DC Inverter Aircon?
A; All units purchased has local manufacturer warranty. 1 year parts & service, 12 years compressor

Q: Do you issue sales invoice Gree GW09-6DCR Primo 1.0 HP Wall Mounted Split Type Full DC Inverter Aircon?
A: Yes, we issue sales invoice.

Q: Are the products authentic ,(Gree GW09-6DCR Primo 1.0 HP Wall Mounted Split Type Full DC Inverter Aircon) original & brand new?
A: Yes, all products are authentic, original & brand new.
